Rim / 622X19C / 36GTS / Double-walled / No eyelets / Vuelta / Sparta 9x4 / Black / Brake surface

Use this rim for assembling a wheel

Choose this rim

Beoogd gebruik	Tour / Hybride , City
BSD maat	622
FIETS Inch maat	28
Aantal spaken/spaakgaten	36
Geschikt voor velgrem	Ja
Kleur	Zwart
Interne breedte van de velg	19C
Merk velg	Vuelta
Type velg	Sparta 9*4
Materiaal van de velg	Aluminium
Enkelwandig / Dubbelwandig	Dubbelwandig
Gebuste velg	Ongebust
Nieuw of gebruikt	Nieuw

Rim Specifications:
Brand:    Vuelta
Model:    Sparta 9*4
Color:    Black
Size (Inch/MM):    622X19C
External width (MM):    25
Internal width (MM):    19
Average weight (GR):    669
Material:    Aluminium
Single-walled / Double-walled:    Double-walled
Single eyelets / Double eyelets:    No eyelets
Number of spoke holes:    36GTS
Spoke nipple size:    13G
Brake surface present:    Yes

Data for spoke length calculations using the Sapim spoke size calculator:
Internal diameter of the rim (MM *Not ERD*):    585
Rim thickness (MM):    2
Number of spokes in the wheel:    36
Number of crossings gear side: of your choice
Number of crossing non-gear side: of your choice

Link to spoke calculator: www.sapim.be/spoke-calculator
