Rim / 622X19C / 32GTS / Double-walled / No eyelets / Rigida - Ryde / X-Plorer / Silver / Brake surface

Use this rim for assembling a wheel

Choose this rim

Beoogd gebruik	Tour / Hybride , City
BSD maat	622
FIETS Inch maat	28
Aantal spaken/spaakgaten	32
Geschikt voor velgrem	Ja
Kleur	Zilver
Interne breedte van de velg	19C
Merk velg	Ryde
Type velg	X-Plorer
Materiaal van de velg	Aluminium
Enkelwandig / Dubbelwandig	Dubbelwandig
Gebuste velg	Ongebust
Nieuw of gebruikt	Nieuw

Rim Specifications:
Brand: Rigida - Ryde
Model: X-Plorer
Color: Silver
Size (Inch/MM): 28" / 622
External width (MM): 24,5
Internal width (MM): 19
Weight (GR): 673
Material: Aluminium
Single-walled / Double-walled: Double-walled
Single eyelets / Double eyelets: No eyelets
Number of spoke holes: 32
Spoke nipple size: 14
Brake surface present: Yes

Data for spoke length calculations using the Sapim spoke size calculator:

Internal diameter of the rim (MM *Not ERD*): 582

Rim thickness (MM): 2

Number of spokes in the wheel: 32

Number of crossings gear side: of your choice

Number of crossing non-gear side: of your choice

Link to spoke calculator: www.sapim.be/spoke-calculator
