Rim / 349X16C / 32GTS / Double-walled / No eyelets / Dahon / Others / Black / Brake surface

Use this rim for assembling a wheel

Choose this rim

Beoogd gebruik	Vouwfiets / Plooifiets
BSD maat	349
FIETS Inch maat	16
Aantal spaken/spaakgaten	32
Geschikt voor velgrem	Ja
Kleur	Zwart
Interne breedte van de velg	16C
Merk velg	Dahon
Type velg	Others
Materiaal van de velg	Aluminium
Enkelwandig / Dubbelwandig	Dubbelwandig
Gebuste velg	Ongebust
Nieuw of gebruikt	Nieuw

Rim Specifications:
Brand: Dahon
Model: Others
Color: Black
Size (Inch/MM): 349X16C
External width (MM): 21
Internal width (MM): 16
Average weight (GR): 287
Material: Aluminium
Single-walled / Double-walled: Double-walled
Single eyelets / Double eyelets: No eyelets
Number of spoke holes: 32GTS
Spoke nipple size: 14G
Brake surface present: Yes

Data for spoke length calculations using the Sapim spoke size calculator:
Internal diameter of the rim (MM *Not ERD*): 318
Rim thickness (MM): 2
Number of spokes in the wheel: 32
Number of crossings gear side: of your choice
Number of crossing non-gear side: of your choice

Link to spoke calculator: www.sapim.be/spoke-calculator
